Design Inspiration:
The designing inspiration of this light is from retro microphone, classics modelling and stand the test of time. The front and back heat sink is conducive to heat dissipation,angle of rotation can be 360 degree adjust. The light body can adjust 180 degree, suitable for any facade.
Scope:
landscape, bridge, building decoration, hotels, cultural facilities, and square, bars discos and other places of entertainment decoration.
Specification
Model | FTFX-DXD-002-1 | FTFX-DXD-002-2 |
Profile Material | Iron Gray Aluminum |
Iron Gray Aluminum |
Light Source | CREE |
CREE |
Dimension | L69*W49*H83mm |
L69*W49*H83mm |
Input Voltage | DC24V | DC24V |
Current | 350mA |
350mA |
LED quantity | 1pcs/3pcs | 1pcs/3pcs |
Power | 6W | 6W |
Color | RGB |
R/G/B/Y/W/Royal blue/Jacinth/Amber |
Protocol | DMX512 | (Constantly on) |
Beam Angle | 120° |
120° |
Working Temperature |
-40~55℃ |
-40~55℃ |
IP Grade | IP67 | IP67 |
Warranty | 30000H-50000H |
30000H-50000H |
Certificate | CE, Rohs | CE, Rohs |
Profile name | Release date | - | |
---|---|---|---|
• 点点洗墙灯 规格书specification | 2018-01-09 | - | Download |
